Lightweight and ready for anything, Osmo Nano lets you capture life’s moments effortlessly, wherever your day takes you. From cycling and running to epic adventures and everyday moments, Osmo Nano delivers crisp, vivid footage that brings every memory to life. Its sleek, magnetic design unlocks bold, new, hands-free shooting angles, helping you tell your story like never before.
-
Dimensions
-
- Camera: 57.3×29.5×28 mm (L×W×H)
- Multifunctional Vision Dock: 59.1×42.2×22.3 mm (L×W×H)
-
-
Weight
-
- Camera: 52 g
- Multifunctional Vision Dock: 72 g
-
-
Waterproof
-
- Camera: up to 10 m
- Camera + Multifunctional Vision Dock: IPX4 splash resistance
Before use, tighten the Glass Lens Cover. It is not recommended to use the camera body only for long-term underwater shooting or in environments with high water impact pressure. Do not use the camera in hot springs or extreme underwater environments, or let it come into contact with corrosive or unknown liquids.
-
-
Number of Microphones
-
- 2
-
-
Touchscreen
-
- Dimensions: 1.96 inches, 326 ppi
- Resolution: 314×556
- Maximum Brightness (typical): 800 cd/㎡
-
-
Supported SD Cards
-
- microSD (up to 1 TB)
-
-
Recommended microSD Cards
-
- Lexar SILVER PLUS 64GB U3 A2 V30 microSDXC
- Lexar SILVER PLUS 128GB U3 A2 V30 microSDXC
- Lexar SILVER PLUS 256GB U3 A2 V30 microSDXC
- Lexar SILVER PLUS 512GB U3 A2 V30 microSDXC
- Lexar SILVER PLUS 1TB U3 A2 V30 microSDXC
- Kingston Canvas Go! Plus 64GB U3 A2 V30 microSDXC
- Kingston Canvas Go! Plus 128GB U3 A2 V30 microSDXC
- Kingston Canvas Go! Plus 256GB U3 A2 V30 microSDXC
- Kingston Canvas Go! Plus 512GB U3 A2 V30 microSDXC
- Kingston Canvas Go! Plus 1TB U3 A2 V30 microSDXC
-
-
Camera
-
Sensor
1/1.3″ CMOS
Lens
FOV: 143°
Aperture: f/2.8
Focus Range: 0.35 m to ∞ISO Range
Photo: 100-25600
Video: 100-25600Electronic Shutter Speed
Photo: 1/8000-30 s
Video: 1/8000 s to the limit of frames per secondMax Photo Resolution
6880 × 5160
Still Photography Modes
Single: Approx. 35 MP
Countdown: Off/0.5/1/2/3/5/10 s
Burst: Up to 30 images/3 sVideo
4K (4:3): 3840 × 2880@24/25/30/48/50fps
4K (16:9): 3840 × 2160@24/25/30/48/50/60fps
2.7K (4:3): 2688 × 2016@24/25/30/48/50/60fps
2.7K (16:9): 2688 × 1512@24/25/30/48/50/60fps
1080p (4:3): 1920 × 1440@24/25/30/48/50/60fps
1080p (16:9): 1920 × 1080@24/25/30/48/50/60fpsSlow Motion
4K: 4x (120fps)
2.7K: 4x (120fps)
1080p: 8x (240fps), 4x (120fps)Hyperlapse
4K/2.7K/1080p@25/30fps: Auto/×2/×5/×10/×15/×30
Timelapse
4K/2.7K/1080p@25/30fps
Intervals: 0.5/1/2/3/4/5/6/8/10/15/20/25/30/40 s, 1/2/5/30/60 min
Duration: 5/10/20/30 min, 1/2/3/5 hours, ∞Stabilization
EIS:
RockSteady 3.0
HorizonBalancing
EIS is not supported in Slow Motion and Timelapse modes. HorizonBalancing is only available when the video resolution is 1080p (16:9), 2.7K (16:9), or 4K (16:9) with a frame rate of 60fps or below.Pre-Rec
Pre-Recording Duration: 5/10/15/30 s, 1/2/5 min
Max Video Bitrate
120 Mbps
Supported File System
exFAT
Photo Format
JPEG/RAW
Video Format
MP4 (HEVC)
Built-in Storage Capacity
64GB Version: 48GB available storage
128GB Version: 107.6GB available storage
The storage capacity can be expanded by inserting a microSD card.Audio Recording
48 kHz 16-bit; AAC
-
-
Battery
-
Type
Camera: Li-ion 1S
Multifunctional Vision Dock: Li-ion 1SCapacity
Camera: 530 mAh
Multifunctional Vision Dock: 1300 mAhEnergy
Camera: 2.041 Wh
Multifunctional Vision Dock: 5.031 WhVoltage
Camera: 3.85 V
Multifunctional Vision Dock: 3.87 VOperating Temperature
-20° to 45° C (-4° to 113° F)
Charging Temperature
5° to 40° C (41° to 104° F)
Operating Time
Camera: 90 min*
Camera + Multifunctional Vision Dock: 200 min*
* Tested at 25° C (77° F) room temperature while recording 1080p/24fps (16:9) video, with RockSteady stabilization enabled, Wi-Fi disabled, and the screen turned off. Actual operating time may vary based on device settings, usage, and environmental factors. Data was collected in a controlled environment and should be taken as reference only.
Endurance Mode: Continuous recording at 4K/60fps for over 50 minutes**
** Measured at 25° C (77° F) room temperature with RockSteady stabilization enabled, Wi-Fi disabled, and the screen turned off.
-
-
Connection
-
Wi-Fi Operating Frequency
2.400-2.4835 GHz
5.725-5.850 GHzWi-Fi Protocol
Wi-Fi 6.0
802.11 a/b/g/n/ac/axWi-Fi Transmitter Power (EIRP)
2.4 GHz: < 23 dBm (FCC), < 20 dBm (CE/SRRC/MIC)
5.8 GHz: < 23 dBm (FCC/SRRC), < 14 dBm (CE)Bluetooth Operating Frequency
2.400-2.4835 GHz
Bluetooth Transmitter Power (EIRP)
Camera: < 13 dBm
Multifunctional Vision Dock: < 10 dBmBluetooth Protocol
Camera: BLE 5.1
Multifunctional Vision Dock: BLE 5.4Transmission Distance
Wireless transmission range between the Multifunctional Vision Dock and the camera: 10 m*
* Measured in an unobstructed environment free of interference.
-
-
What's in the box
-
- Osmo Nano Camera
- Osmo Nano Multifunctional Vision Dock
- Osmo Nano Magnetic Hat Clip
- Osmo Nano Magnetic Lanyard
- Osmo Nano Protective Case
- USB-C to USB-C PD Cable (USB 3.1)
- Osmo Nano Dual-Direction Magnetic Ball-Joint Adapter Mount
-
